| Type of Product | Potentiometer |
| Resistance | 5 kOhms |
| Tolerance | 0.2 |
| Type | Heavy Duty |
Type of Product |
Potentiometer |
Resistance |
5 kOhms |
Tolerance |
0.2 |
Type |
Heavy Duty |
Series |
P30L |
Country of Origin |
- |
Termination Style |
Solder Lug Termination |
Shaft Diameter |
6 mm |
Power Rating |
3 W |
Mounting Type |
Panel Mount |
Number of Turns |
1 Turn |
Shaft Type |
Smooth |
Shaft Length |
50 mm |
No. of Gangs |
1 Gang |
Taper |
Linear |
IP Rating |
IP67 |
Switch Type |
No Switch |
Voltage Rating |
122 V |
Name of Manufacturer/Packer/Importer |
Vishay / Sfernice |
Maximum Operating Temperature |
+ 125 C |
Minimum Operating Temperature |
- 55 C |
Ordering ID |
72-P30LL0FRR502MA |
Manufacturer Part Number |
P30LL0FRR502MA |
RoHS Compliant |
RoHS Compliant By Exemption |
Packaging Type |
Blister Pack |
Element Type |
Cermet |
Bush Size |
10 mm |
No. of Detents |
Without Detent |
Product |
Potentiometers |
Life Cycle |
2000000 Cycle |
