| Cable Type | NYY-J |
| Type of Product | Power Cable |
| Model No | 9028316 |
| Conductor Material | Copper Conductor |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Cable Type |
NYY-J |
Type of Product |
Power Cable |
Model No |
9028316 |
Conductor Material |
Copper Conductor |
No of Core |
4 Core |
Voltage Rating |
600 V-1 kV |
Nominal Area |
6 Sqmm |
Insulation Material |
PVC Insulated |
Sheath Material |
PVC |
Color |
Black |
Length |
50 m |
Country of Origin |
United Kingdom |
Stranded Size |
2.69 mm |
Standard Met |
EN 50265-2-1, IEC 60228 Class 1, IEC 60332-1, IEC 60502-1, RoHS Compliant |
Conductor Resistance |
3.08 Ω/km |
Maximum Operating Temperature |
+70°C |
Conductor Type |
Solid |
Minimum Operating Temperature |
-5°C |
Fire Extinguisher Type |
Flame Retardant |
Armoured / Unarmoured |
- |
Name of Manufacturer/Packer/Importer |
RS Component |
