| Cable Type | TRS |
| Type of Product | Power Cable |
| Model No | 8634014 |
| Conductor Material | Copper Conductor |
Cable Type |
TRS |
Type of Product |
Power Cable |
Model No |
8634014 |
Conductor Material |
Copper Conductor |
No of Core |
3 Core |
Voltage Rating |
300-500 V |
Nominal Area |
1.5 Sqmm |
Insulation Material |
EPDM Insulated |
Sheath Material |
CPE |
Current Rating |
16 A |
Color |
Black |
Length |
100 m |
No. of Strands |
30 |
Country of Origin |
China |
Stranded Size |
0.24 mm |
Standard Met |
Euroclass Eca |
Conductor Resistance |
13.3 Ω/km |
Wire Gauge |
15 AWG |
Outer Diameter |
8.5-8.9 mm |
Maximum Operating Temperature |
+60°C |
Conductor Type |
Stranded |
Minimum Operating Temperature |
-25°C |
Strands |
30/0.24 mm |
Harmonization Code |
H05RR-F |
Armoured / Unarmoured |
- |
Name of Manufacturer/Packer/Importer |
RS Component |
