| Type of Product | Tesys Contactor |
| No. of Pole | 3P |
| Model No | LC1D126BD |
| Type | Non-reversible type |
Type of Product |
Tesys Contactor |
No. of Pole |
3P |
Model No |
LC1D126BD |
Type |
Non-reversible type |
Series |
D Series |
Auxiliary Contacts |
1NO+1NC |
Specifications |
●Product group: TeSys Deca●Protective cover: Yes●Signal circuit frequency (Hz): 25 to 400●Overvoltage category: III |
Rated Current (A) |
12 (AC class 3) |
Standard |
CSA C22.2 No 14/EN 60947-4-1/EN 60947-5-1/IEC 60947-4-1/IEC 60947-5-1/UL 508/IEC 60335-1 |
Range |
TeSys |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Arrow & Harmony (Schneider Electric) |
Contact Configuration |
3NO |
Import Country |
Direct Import from Japan |
Monotaro ID |
7807503 |
Connecting Terminal |
lugs/bars terminals |
Insulation Resistance (MOhm) |
>10 for signalling circuit |
Allowable Ambient Temperature (℃) |
-40 to 60, 60 to 70 (with derating) |
Motor Capacity (kW) |
3 at 220 to 230VAC 50/60Hz(AC-3), 5.5 at 380 to 400VAC 50/60Hz(AC-3), 5.5 at 415VAC 50/60Hz(AC-3), 5.5 at 440VAC 50/60Hz(AC-3), 7.5 at 500VAC 50/60Hz(AC-3), 7.5 at 660 to 690VAC 50/60Hz(AC-3), 3 at 220 to 230VAC 50/60Hz(AC-3e), 5.5 at 380 to 400VAC 50/60Hz(AC-3e), 5.5 at 415VAC 50/60Hz(AC-3e), 5.5 at 440VAC 50/60Hz(AC-3e), 7.5 at 500VAC 50/60Hz(AC-3e), 7.5 at 660 to 690VAC 50/60Hz(AC-3e), 3.7 at 400VAC 50/60Hz(AC-4) |
Flame Retardance |
V1 UL 94 |
Mount Type |
Plate, rail |
Mass (Kg) |
0.48499999999999999 |
Ambient Temperature / Supply Air Temperature (℃) |
-40 to 60, 60 to 70 (with derating) |
Protection Class |
IP20 front according to IEC 60529 |
Power Consumption (W) |
(per pole)0.36 AC-3, 1.56 AC-1, 0.36 AC-3e |
Operation Type |
Irreversible |
Electrode Capacity |
3P |
