| Contact Configuration | SPST-NC, SPST-NO |
| Coil Resistance | 7250 Ω |
| No. of Pole | 1 |
| Type of Product | Power Relay |
Contact Configuration |
SPST-NC, SPST-NO |
Coil Resistance |
7250 Ω |
No. of Pole |
1 |
Type of Product |
Power Relay |
Application |
Power |
Mounting Type |
Flange Mount |
Series |
65 Series |
Coil Voltage |
230 V AC |
Height |
36.5 mm |
Length |
62.2 mm |
Terminal Type |
Quick Connect |
Latching |
No |
Switching Current |
20 A |
Depth |
32.2 mm |
Coil Power Consumption |
2.2 W |
Country of Origin |
Italy |
Isolation Coil To Contact |
4 kV |
Maximum Operating Temperature |
+75°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
5 kVA |
Maximum Switching Voltage (AC) |
250 V AC |
Manufacturer Part Number |
65.31.8.230.0000 |
Standards Met |
CE, EAC |
Operating Cycle |
80000 Cycles |
