| Contact Configuration | SPST |
| No. of Pole | 1 |
| Type of Product | Power Relay |
| Contact Material | Silver Alloy |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
SPST |
No. of Pole |
1 |
Type of Product |
Power Relay |
Contact Material |
Silver Alloy |
Mounting Type |
PCB Mount |
Series |
43 Series |
Coil Voltage |
12 V DC |
Height |
15.4 mm |
Length |
28.6 mm |
Terminal Type |
Through Hole |
Latching |
No |
Switching Current |
16 A |
Depth |
10.2 mm |
Coil Power Consumption |
400 mW |
Country of Origin |
US |
Isolation Coil To Contact |
6 kV |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
2.5 kVA |
Maximum Switching Voltage (AC) |
400 V AC |
Manufacturer Part Number |
43.61.9.012.2300 |
Operating Cycle |
100000 (Electrical) Cycles, 10000000 (Mechanical) Cycles |
