| Contact Configuration | SPST |
| No. of Pole | 1 |
| Type of Product | Power Relay |
| Application | Interposing Lighting Switching |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
SPST |
No. of Pole |
1 |
Type of Product |
Power Relay |
Application |
Interposing Lighting Switching |
Mounting Type |
Switch Box |
Series |
13 Series |
Coil Voltage |
24 V DC |
Height |
39 mm |
Length |
37 mm |
Terminal Type |
Screw |
Switching Current |
12 A |
Depth |
22.7 mm |
Coil Power Consumption |
400 mW |
Country of Origin |
Italy |
Isolation Coil To Contact |
2 kV |
Maximum Operating Temperature |
+60°C |
Minimum Operating Temperature |
-10°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
3 kVA |
Maximum Switching Voltage (AC) |
400 V AC |
Manufacturer Part Number |
13.31.9.024.4300 |
Operating Cycle |
70000 (Electrical) Cycles |
