| Contact Configuration | 3PDT |
| Coil Resistance | 74 Ω |
| No. of Pole | 3 |
| Type of Product | Power Relay |
Contact Configuration |
3PDT |
Coil Resistance |
74 Ω |
No. of Pole |
3 |
Type of Product |
Power Relay |
Application |
Power |
Mounting Type |
Plug In |
Series |
62 Series |
Coil Voltage |
24 V AC |
Height |
35.8 mm |
Length |
38.2 mm |
Terminal Type |
Quick Connect |
Latching |
No |
Switching Current |
16 A |
Depth |
49.1 mm |
Coil Power Consumption |
2.2 W |
Country of Origin |
Italy |
Isolation Coil To Contact |
6 kV |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
4 kVA |
Maximum Switching Voltage (AC) |
400 V AC |
Manufacturer Part Number |
62.33.8.024.0040 |
Operating Cycle |
10000000 (AC Mechanical) Cycles, 20000000 (DC Mechanical) Cycles |
