| Contact Configuration | DPDT |
| Coil Resistance | 900 Ω |
| No. of Pole | 2 |
| Type of Product | Power Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
DPDT |
Coil Resistance |
900 Ω |
No. of Pole |
2 |
Type of Product |
Power Relay |
Mounting Type |
PCB Mount |
Series |
40 Series |
Coil Voltage |
24 V DC |
Height |
25 mm |
Length |
29 mm |
Terminal Type |
Plug In |
Latching |
No |
Switching Current |
8 A |
Depth |
12.4 mm |
Coil Power Consumption |
650 mW |
Country of Origin |
Italy |
Isolation Coil To Contact |
6 kV |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Voltage (AC) |
400 V |
Manufacturer Part Number |
40.52.9.024.0000 |
Operating Cycle |
10 x 10⁶ Cycles |
