| Contact Configuration | SPST-NC, SPST-NO |
| Coil Resistance | 27 Ω |
| No. of Pole | 3 |
| Type of Product | Latching Modular Step Relay |
Contact Configuration |
SPST-NC, SPST-NO |
Coil Resistance |
27 Ω |
No. of Pole |
3 |
Type of Product |
Latching Modular Step Relay |
Mounting Type |
DIN Rail |
Series |
20 Series |
Coil Voltage |
24 V AC |
Height |
84 mm |
Terminal Type |
Screw |
Latching |
Yes |
Switching Current |
16 A |
Depth |
58.4 mm |
Coil Power Consumption |
6.5 W |
Country of Origin |
Italy |
Isolation Coil To Contact |
4 kV |
Maximum Operating Temperature |
+40°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
4 kVA |
Maximum Switching Voltage (AC) |
250 V AC |
Manufacturer Part Number |
20.23.8.024.0000 |
Standards Met |
CE, EAC |
Operating Cycle |
300000 Cycles |
