| Contact Configuration | DPDT |
| Coil Resistance | 1.15 kO |
| No. of Pole | 2 |
| Type of Product | PCB Mount Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
DPDT |
Coil Resistance |
1.15 kO |
No. of Pole |
2 |
Type of Product |
PCB Mount Relay |
Mounting Type |
PCB Mount |
Series |
40 Series |
Dimension |
12.4x25x29 mm |
Coil Voltage |
24 V DC |
Latching |
No |
Switching Current |
10 A |
Coil Power Consumption |
500 mW |
Country of Origin |
Italy |
Isolation Coil To Contact |
6 kV |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
750 VA |
Maximum Switching Power DC |
300 mW |
Maximum Switching Voltage (AC) |
400 V AC |
Manufacturer Part Number |
406270240000 |
Standards Met |
cRUus Recognized, CSA, EAC |
Operating Cycle |
100000 Cycles |
