| Contact Configuration | DPDT |
| Coil Resistance | 600 Ω |
| No. of Pole | 2 |
| Type of Product | Power Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
DPDT |
Coil Resistance |
600 Ω |
No. of Pole |
2 |
Type of Product |
Power Relay |
Application |
General Purpose |
Mounting Type |
Plug In |
Series |
56 Series |
Coil Voltage |
24 V DC |
Height |
37.2 mm |
Length |
27.7 mm |
Terminal Type |
Quick Connect |
Latching |
No |
Switching Current |
12 A |
Depth |
20.7 mm |
Coil Power Consumption |
1.5 W |
Country of Origin |
Italy |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
3 kVA |
Maximum Switching Voltage (AC) |
400 V AC |
Manufacturer Part Number |
56.32.9.024.0040 |
Standards Met |
CE, EAC |
Operating Cycle |
100000 Cycles |
