| Contact Configuration | SPDT |
| Coil Resistance | 28000 Ω |
| No. of Pole | 1 |
| Type of Product | PCB Mount Relay |
Contact Configuration |
SPDT |
Coil Resistance |
28000 Ω |
No. of Pole |
1 |
Type of Product |
PCB Mount Relay |
Application |
PCB |
Mounting Type |
PCB Mount |
Series |
40 Series |
Coil Voltage |
230 V AC |
Height |
25 mm |
Length |
29 mm |
Terminal Type |
Through Hole |
Latching |
No |
Switching Current |
12 A |
Depth |
12.4 mm |
Coil Power Consumption |
1.2 W |
Country of Origin |
Italy |
Isolation Coil To Contact |
6 kV |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
2.5 kVA |
Maximum Switching Voltage (AC) |
400 V AC |
Manufacturer Part Number |
40.31.8.230.0000 |
Standards Met |
EAC |
Operating Cycle |
10000000 Cycles |
