| Contact Configuration | 4PDT |
| Coil Resistance | 4000 Ω |
| No. of Pole | 4 |
| Type of Product | Power Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
4PDT |
Coil Resistance |
4000 Ω |
No. of Pole |
4 |
Type of Product |
Power Relay |
Application |
Power |
Mounting Type |
PCB Mount |
Series |
55 Series |
Coil Voltage |
110 V AC |
Height |
35.8 mm |
Length |
27.7 mm |
Terminal Type |
Through Hole |
Latching |
No |
Switching Current |
7 A |
Depth |
20.7 mm |
Coil Power Consumption |
1.5 W |
Country of Origin |
Italy |
Isolation Coil To Contact |
4 kV |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
1.75 kVA |
Maximum Switching Voltage (AC) |
250 V AC |
Manufacturer Part Number |
55.14.8.110.0000 |
