| Contact Configuration | SPDT |
| No. of Pole | 1 |
| Type of Product | Power Relay |
| Application | Compact |
Contact Configuration |
SPDT |
No. of Pole |
1 |
Type of Product |
Power Relay |
Application |
Compact |
Contact Material |
Silver Alloy |
Mounting Type |
PCB Mount |
Series |
32 Series |
Coil Voltage |
24 V DC |
Height |
10.7 mm |
Length |
20 mm |
Terminal Type |
Through Hole |
Latching |
No |
Switching Current |
6 A |
Depth |
10 mm |
Coil Power Consumption |
200 mW |
Country of Origin |
US |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Maximum Switching Power AC |
1.5 kVA |
Maximum Switching Voltage (AC) |
250 V AC |
Manufacturer Part Number |
32.21.7.024.2000 |
Operating Cycle |
20000000 (Electrical) Cycles, 20000000 (Mechanical) Cycles |
