| Contact Configuration | SPST |
| Coil Resistance | 68 Ω |
| No. of Pole | 1 |
| Type of Product | Power Relay |
Contact Configuration |
SPST |
Coil Resistance |
68 Ω |
No. of Pole |
1 |
Type of Product |
Power Relay |
Mounting Type |
PCB Mount |
Series |
FTR-H2 |
Coil Voltage |
6 V DC |
Height |
25 mm |
Length |
24 mm |
Terminal Type |
PCB Pin |
Latching |
No |
Switching Current |
10 Amp |
Depth |
11 mm |
Coil Power Consumption |
530 mW |
Country of Origin |
China |
Isolation Coil To Contact |
4000 (Dielectric) V AC |
Name of Manufacturer/Packer/Importer |
Fujitsu |
Maximum Switching Power AC |
2.5 kVA |
Maximum Switching Current DC |
10 Amp |
Maximum Switching Power DC |
300 W |
Maximum Switching Voltage DC |
300 V DC |
Maximum Switching Current AC |
10 Amp |
Product Code |
1958213 |
Manufacturer Part Number |
FTR-H2AK006T |
Maximum Switching Voltage AC |
400 V AC |
