| Contact Configuration | SPST |
| Coil Resistance | 1440 Ω |
| No. of Pole | 1 |
| Type of Product | Power Relay |
Contact Configuration |
SPST |
Coil Resistance |
1440 Ω |
No. of Pole |
1 |
Type of Product |
Power Relay |
Application |
Power |
Contact Material |
Silver Alloy |
Mounting Type |
PCB Mount |
Coil Voltage |
24 V DC |
Height |
15.7 mm |
Length |
29 mm |
Terminal Type |
PCB Pin |
Latching |
No |
Switching Current |
16 Amp |
Depth |
12.7 mm |
Coil Power Consumption |
400 mW |
Country of Origin |
United Kingdom |
Isolation Coil To Contact |
10 kV |
Life Expectancy |
100x10³ Operations |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
Fujitsu |
Maximum Switching Power AC |
4 kVA |
Maximum Switching Power DC |
384 W |
Maximum Switching Voltage DC |
300 V DC |
Product Code |
7903331 |
Manufacturer Part Number |
FTR-K1AK024T |
Maximum Switching Voltage AC |
440 V AC |
