| Contact Configuration | SPST |
| Coil Resistance | 2880Ω |
| No. of Pole | 1 |
| Type of Product | Power Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
SPST |
Coil Resistance |
2880Ω |
No. of Pole |
1 |
Type of Product |
Power Relay |
Contact Material |
Silver Alloy |
Series |
HF163F-L |
Dimension |
24 x 10 x 18.8mm |
Coil Voltage |
24V dc |
Height |
18.8mm |
Length |
24mm |
Terminal Type |
PCB Pin |
Latching |
Yes |
Switching Current |
10A |
Depth |
10mm |
Coil Power Consumption |
200mW |
Country of Origin |
China |
Isolation Coil To Contact |
5kV ac |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
Hongfa Europe GMBH |
Maximum Switching Power AC |
2.5 kVA |
Maximum Switching Current DC |
10 A |
Maximum Switching Voltage DC |
30V dc |
Maximum Switching Current AC |
10 A |
Maximum Switching Voltage (AC) |
250V |
Maximum Switching Voltage (DC) |
30V dc |
Maximum Switching Current (AC) |
10 A |
Maximum Switching Current (DC) |
10 A |
Pack of |
40 Pcs |
Manufacturer Part Number |
HF163F-L/24-HL1T |
Standards Met |
cULus File No:E134517, VDE File No:40039460 |
Operating Cycle |
1 x 10^6 cycles |
