Ships within 19 days
Model No
View
View
View
View
| Coil Voltage Rating (V) | DC12 |
| Mass (g) | About 12 |
| Return Voltage | More than 10 |
| Contact Configuration | 2C |
Coil Voltage Rating (V) |
DC12 |
Mass (g) |
About 12 |
Return Voltage |
More than 10 |
Contact Configuration |
2C |
Mechanical Durability |
20 million times or more (opening and closing frequency 18000 times / h) |
Type |
Power relay |
Contact Mechanism |
single |
Coil Resistance |
360 ± 10% (Coil temperature + 23 ℃) |
Rated Voltage (V) |
DC12 |
Return Time (ms) |
5 or less |
Contact Resistance |
100 or less (DC5V 1A voltage drop method) |
Rated Carrying Current (A) |
(Contact) 5 |
No. of Pole |
2 Pole |
Vibration Resistance (Endurance) |
10 to 55 to 10 Hz, single amplitude 0.75 mm (double amplitude 1.5 mm) |
Insulation Resistance |
1000 or more (with DC500V mega) |
Operating Time (ms) |
15 or less |
Monotaro ID |
39065381 |
Vibration Resistance (Mis-operation) |
10 to 55 to 10 Hz, single amplitude 0.75 mm (double amplitude 1.5 mm) |
Operating Voltage |
70% or less |
Type of Product |
Power Relay |
Model No |
G2RL-2 DC12 |
Contact Material |
Ag alloy (Cd-free material) |
Shock Resistance |
1000m/s<sup>2</sup> |
Ambient Humidity to Use |
5～85%RH |
Series |
G2RL Series |
Classification |
Standard type |
Rated Current (mA) |
33.3 ± 10% (Coil temperature + 23 ℃) |
Electrical Durability |
Resistance load / AC250V 5A 50,000 times (opening and closing frequency 1800 times / h) |
Withstand voltage (V / min) |
コイルと接点間/AC5000(50/60Hz) 同極接点間/AC1000(50/60Hz) 異極接点間/AC2500(50/60Hz) |
Operation Ambient Temperature |
-40 to +85 (with no icing or condensation) |
Maximum Contact Voltage (V) |
AC440、DC300 |
Maximum Switching Frequency (times/h), at Rated Load |
1800 |
Failure Rate P Level (Reference Value: at Switching Frequency 120 times/min) |
DC24V 40mA |
Maximum Switching Frequency (times/h), Mechanical |
18000 |
Maximum Allowable Voltage (V) |
130%(at85℃) |
Maximum contact current (A) |
5 |
Impact Resistant Voltage (V) |
10k(1.2×50μs) |
Rated Load |
(Contact) AC250V 5A |
Maximum Power Consumption (mW) |
About 400 |
Country of Origin |
Malaysia |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
