| Mass (g) | About 90 |
| Terminal Shape | Tab terminal # 250 |
| Operating Temperature Range | -25 to 60℃ |
| Contact Configuration | A Contact Point |
Mass (g) |
About 90 |
Terminal Shape |
Tab terminal # 250 |
Operating Temperature Range |
-25 to 60℃ |
Contact Configuration |
A Contact Point |
Rated Voltage (V) |
AC 100/120 |
No. of Pole |
1 Pole |
Power Consumption |
About 1.7 to 2.5 |
Insulation Resistance |
100 or more (measured with the DC500V insulation resistance meter at the same location as the withstand voltage) |
Withstand Voltage |
Between coil and contacts: AC4000 50/60Hz, Between same pole contacts: AC2000 50/60Hz |
Monotaro ID |
39070333 |
Type of Product |
Power Relay |
Model No |
G7L-1A-TUB AC100/120 |
Series |
G7L |
Protection Class |
In a case |
Coil Voltage |
AC100/120 V |
Type of Sign |
Upper bracket installation |
Country of Origin |
Indonesia |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to +60 (with no icing or condensation) |
Category |
Power Relay |
Installation Method |
Upper Bracket Mounting |
