Ships within 19 days
Model No
View
View
View
View
| Mass (g) | About 395 |
| Terminal Shape | Plug-In Terminal |
| Return Voltage | Rated voltage: 10% or less |
| Operating Temperature Range | -10 to 55 ℃ (no condensation or freezing) |
Mass (g) |
About 395 |
Terminal Shape |
Plug-In Terminal |
Return Voltage |
Rated voltage: 10% or less |
Operating Temperature Range |
-10 to 55 ℃ (no condensation or freezing) |
Contact Configuration |
3C |
Mechanical Durability |
5 million operations or more (opening / closing frequency 7200 operations / h) |
Type |
Power Relay |
No. of Pole |
3 |
Power Consumption |
About 2.7 |
Monotaro ID |
46647097 |
Operating Voltage |
Rated voltage: 70% or less |
Type of Product |
Power Relay |
Model No |
MM3XP-DC24 |
Contact Material |
Ag |
Shock Resistance |
1000 m/s² |
Ambient Humidity to Use |
5 to 85%Rh |
Classification |
DC load switching type |
Electrical Durability |
500,000 operations or more (Rated load switching frequency 1800 times / h) |
Shape |
Cased type |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-10 to +55 (with no icing or condensation) |
Contact Resistance (ohm) |
50 mΩ or Less (DC 5 V 1 Amp voltage drop method) |
Insulation Resistance (MOhm) |
100 or more (measured with the DC500V insulation resistance meter at the same location as the withstand voltage) |
Rated Coil Voltage |
DC 24 V |
