Ships within 19 days
Model No
View
View
View
View
| Mass (g) | About 140 g |
| Terminal Shape | Tab Terminals |
| Operating Temperature Range | -25~60°C (No Condensation or Freezing) |
| Contact Configuration | 4A |
Mass (g) |
About 140 g |
Terminal Shape |
Tab Terminals |
Operating Temperature Range |
-25~60°C (No Condensation or Freezing) |
Contact Configuration |
4A |
Rated Voltage (V) |
AC100/120 |
Power Consumption |
About 1.8-2.6 |
Insulation Resistance |
1000 mΩ or more (DC500 V) |
Withstand Voltage |
Between Coil and Contact, Between Contacts of Different Polarities: AC4000 V 50/60 Hz, Between Contacts of the Same Polarity: AC2000V 50/60 Hz |
Monotaro ID |
39070157 |
Type of Product |
Power Relay |
Model No |
G7J-4A-T AC100/120 |
Series |
G7J Series |
Protection Class |
In a Case |
Height (mm) |
64 mm |
Type of Sign |
W Bracket Installation |
Length (mm) |
51.5 mm |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
