| Mass (g) | About 120 |
| Return Voltage | More than 15% |
| Operating Temperature Range | -25 to 60℃ (no condensation or freezing) |
| Contact Configuration | A Contact |
Mass (g) |
About 120 |
Return Voltage |
More than 15% |
Operating Temperature Range |
-25 to 60℃ (no condensation or freezing) |
Contact Configuration |
A Contact |
Mechanical Durability |
1,000,000 times or more (opening / closing frequency 1800 times / h) |
Type |
Power relay |
No. of Pole |
2 |
Power Consumption |
About 1.7 to 2.5 |
Monotaro ID |
46644184 |
Operating Voltage |
75% or less |
Type of Product |
Power Relay |
Model No |
G7L-2A-BUB-AC24 |
Shock Resistance |
1000 m/s² |
Electrical Durability |
100,000 operations or more (Rated load switching frequency 1800 times/h) |
Protection Class |
In a case |
Type of Sign |
Upper bracket installation |
Country of Origin |
INDONESIA |
Import Country |
Direct Import from Japan |
Terminal Structure |
Screw terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to +60 (with no icing or condensation) |
Contact Resistance (ohm) |
50 mΩ or less (DC5V 1A voltage drop method) |
Insulation Resistance (MOhm) |
100 or more (measured with the DC 500 V insulation resistance meter at the same location as the withstand voltage) |
Rated Coil Voltage |
AC 24 V |
