| Mass (g) | About 2.7 |
| Terminal Shape | Printed Circuit Board Terminal |
| Contact Configuration | 1C |
| Function | Single staple type |
Mass (g) |
About 2.7 |
Terminal Shape |
Printed Circuit Board Terminal |
Contact Configuration |
1C |
Function |
Single staple type |
Type |
Printed circuit board relays |
Rated Voltage (V) |
DC 48 |
No. of Pole |
1 Pole |
Monotaro ID |
39069213 |
Type of Product |
Micro Relay |
Standard |
UL (No.E41515), CSA (No.LR31928) standard certified standard product |
Model No |
G6E-134P-US DC48 |
Shock Resistance |
1000 m/s² |
Ambient Humidity to Use |
5 to 85%Rh |
Classification |
Standard type |
Protection Class |
Plastic seal type |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 to 10Hz Single Amplitude 1.65Mm (Double Amplitude 3.3Mm) |
Vibration Resistance (Destruction) |
10 to 55 to 10 Hz, single amplitude 2.5 mm (double amplitude 5 mm) |
Terminal Structure |
Printed Circuit Board Terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-40 to +70 (with no icing or condensation) |
Contact Resistance (ohm) |
50 mΩ or less (DC 5 V 1 Amp voltage drop method) |
Insulation Resistance (MOhm) |
1000 or more (with DC 500 V mega) |
Specifications |
Non-ultrasonic cleaning type |
Remark |
Confirm Delivery Date Each Time |
