Ships within 25 days
View
View
View
View
| Mass (g) | About 50 |
| Terminal Shape | PCB terminal |
| CR Circuit | None |
| Operating Temperature Range | -25 to 60℃ (no condensation or freezing) |
Mass (g) |
About 50 |
Terminal Shape |
PCB terminal |
CR Circuit |
None |
Operating Temperature Range |
-25 to 60℃ (no condensation or freezing) |
Contact Configuration |
4C |
Type |
Sealed Relay |
No. of Pole |
4 Pole |
Power Consumption |
About 0.9 |
Monotaro ID |
46666216 |
Type of Product |
Mini Power Relay |
Model No |
MY4ZH-0-DC100/110 |
Classification |
Standard type |
Protection Class |
Hermetically sealed type |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Outer Dimensions |
22 or less x 40.5 or less x 28.5 or less mm |
With or Without Diode |
None |
No. Of Pin |
14 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to 60 (no freezing or condensation) |
Contact Resistance (ohm) |
50 mΩ or less (DC 5 V 1 Amp voltage drop method) |
Insulation Resistance (MOhm) |
100 or more (measured with the DC500V insulation resistance meter at the same location as the withstand voltage) |
Rated Coil Voltage |
DC 100/110 V |
Remark |
Confirm Delivery Date Each Time |
