| Mass (g) | About 4.5 |
| Terminal Shape | Printed circuit board terminal |
| Contact Configuration | 2B Contact |
| Function | Single stable type |
Mass (g) |
About 4.5 |
Terminal Shape |
Printed circuit board terminal |
Contact Configuration |
2B Contact |
Function |
Single stable type |
Type |
Power relay |
Rated Voltage (V) |
DC12 |
No. of Pole |
2-Pole |
Monotaro ID |
8588221 |
Type of Product |
Power Relay |
Standard |
UL, CSA standard certified standard product |
Shock Resistance |
1000m/s² |
Ambient Humidity to Use |
5 to 85%RH |
Classification |
Standard type |
Terminal Fitting Type |
Dedicated type for PCB mounting |
Power Consumption (mW) |
About 300 |
Protection Class |
Plastic seal type |
Coil Voltage |
DC12 V |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10~55~10 Hz, single amplitude 0.75 mm (double amplitude 1.5 mm) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to +70 (with no icing or condensation) |
Manufacturer Part Number |
G6B-2014P-US DC12V |
Contact Resistance (ohm) |
30 or less (DC5V 1A voltage drop method) |
Insulation Resistance (MOhm) |
1000 or more (DC500V) |
Specifications |
Standard type |
