| Mass (g) | About 5.4 |
| Terminal Shape | Printed circuit board terminal |
| Contact Configuration | 1a |
| Function | Single stable type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Mass (g) |
About 5.4 |
Terminal Shape |
Printed circuit board terminal |
Contact Configuration |
1a |
Function |
Single stable type |
Type |
Power relay |
Rated Voltage (V) |
DC12 |
No. of Pole |
1 pole |
Monotaro ID |
39068583 |
Type of Product |
Power Relay |
Standard |
UL, CSA standard certified standard product |
Model No |
G6B-1177P-ND-US DC12 |
Shock Resistance |
1000m/s² |
Classification |
High capacity operation indicator + diode built-in |
Terminal Fitting Type |
Dedicated type for PCB mounting |
Protection Class |
Flux resistant type |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10~55~10 Hz, single amplitude 0.75 mm (double amplitude 1.5 mm) |
Operation Indicator |
LED |
Terminal Structure |
Printed circuit board terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Pack of |
1 Pcs |
Operation Ambient Temperature (°C) |
-25 to +70 (with no icing or condensation) |
Contact Resistance (ohm) |
30 or less (DC5V 1A voltage drop method) |
Insulation Resistance (MOhm) |
1000 mohm or more (DC500 V) |
Specifications |
Standard type |
Rated Coil Voltage |
DC12 |
