Ships within 19 days
Contact Configuration
Model No
View
View
View
View
| Mass (g) | About 330 |
| Terminal Shape | Screw terminal |
| Contact Configuration | 2a2b (relay body), 2a (auxiliary contact) |
| No. of Pole | 4 + 2 (relay body + auxiliary contact) |
Mass (g) |
About 330 |
Terminal Shape |
Screw terminal |
Contact Configuration |
2a2b (relay body), 2a (auxiliary contact) |
No. of Pole |
4 + 2 (relay body + auxiliary contact) |
Monotaro ID |
47910565 |
Type of Product |
Power Relay |
Model No |
G7Z-2A2B-20Z-R 24VDC |
Shock Resistance |
(When screw mounted) 700m/ <sup>s2</sup><br> (When mounted on a DIN rail) 500m/ <sup>s2</sup> |
Ambient Humidity to Use |
5 to 85%RH |
Power Consumption (W) |
About 3.7 |
Series |
G7Z Series |
Terminal Screw |
Relay body / (Contact) M5, (Coil) M3.5 |
Protection Class |
In a case |
Height (mm) |
62 |
Length (mm) |
45 |
Auxiliary Contacts |
Crossbar Twin Contact (Single Break) |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10 to 55 to 10 Hz, single amplitude 0.5 mm (double amplitude 1.0 mm) |
Terminal Structure |
Wire connection method: Screw terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Pack of |
1 Pcs |
Operation Ambient Temperature (°C) |
-25 to + 60 ° C (with no icing or condensation) |
Contact Resistance (ohm) |
400 or less (DC5V 1A voltage drop method) |
Insulation Resistance (MOhm) |
1000 mohm or more (at 1000 V DC) |
Rated Coil Voltage |
DC24 |
