Ships within 19 days
Model No
View
View
View
View
| Mass (g) | About 225 g |
| Diode | Included |
| Terminal Shape | Plug-in Terminals |
| Operating Temperature Range | -10~55°C (No Condensation or Freezing) |
Mass (g) |
About 225 g |
Diode |
Included |
Terminal Shape |
Plug-in Terminals |
Operating Temperature Range |
-10~55°C (No Condensation or Freezing) |
Contact Configuration |
2c |
Rated Voltage (V) |
DC100/110 |
Contact Resistance |
50 mΩ or less (DC5 V 1 A Voltage Drop Method) |
No. of Pole |
2 Pole |
Power Consumption |
About 2.1 |
Insulation Resistance |
100 mΩ or more (Measured with the DC500 V Insulation Resistance Meter at the Same Location as the Withstand Voltage) |
Withstand Voltage |
Between Coil and Contact, Between Contacts of Different Polarities: AC2000 V/min 50/60 Hz, Between Contacts of the Same Polarity: AC1500 V/min 50/60 Hz |
Monotaro ID |
39087946 |
Type of Product |
Power Relay |
Model No |
MM2XP-D DC100/110 |
Structure |
Cased Type |
Series |
MM Series |
Classification |
Built-In Diode for Dc Load Switching |
Operation Ambient Temperature |
-10°C to +55°C (With No Icing or Condensation) |
Shape |
Cased Type |
Protection Class |
In a Case |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
With or Without Diode |
Included |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
