Ships within 25 days
View
View
View
View
| Terminal Shape | Printed Circuit Board Terminal |
| Contact Configuration | 1A |
| Type | Power Relay |
| Contact Mechanism | Single |
Terminal Shape |
Printed Circuit Board Terminal |
Contact Configuration |
1A |
Type |
Power Relay |
Contact Mechanism |
Single |
Rated Voltage (V) |
DC 100 |
Monotaro ID |
46638575 |
Type of Product |
Power Relay |
Model No |
G4W-1112P-US-TV8-DC100 |
Contact Material |
Ag alloy (Cd-free material) |
RoHS Directive |
Correspondence |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Coil Rating |
DC 100 V 8 mA |
Terminal Structure |
Printed Circuit Board Terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Rated Load Voltage (V) |
AC 250 V 15A (resistive load (cosΦ=1)) AC 250 V 10A (inductive load (cosΦ=0.4)) DC24V 15A (resistive load) DC24V 7.5A (inductive load (L/R=7ms)) |
Remark |
Confirm Delivery Date Each Time |
