| Mass (g) | 0.4 |
| Terminal Shape | Printed Circuit Board Terminal |
| Contact Configuration | 1A |
| Type | Printed circuit board relays |
Mass (g) |
0.4 |
Terminal Shape |
Printed Circuit Board Terminal |
Contact Configuration |
1A |
Type |
Printed circuit board relays |
Return Time (ms) |
0.1 (standard), 1.0 (max) |
Operating Time (ms) |
0.3 (standard), 1.0 (max) |
Monotaro ID |
39067217 |
Type of Product |
Mos Fet Relay |
Model No |
G3VM-401BY |
Part No |
64-3361-91 |
Withstand voltage (V / min) |
Between input and output / 5000 (AC 1 minute) |
Shape |
DIP6 |
Leakage Current (mA) |
Output side open circuit / 1 × 10 ¯³ (at 400V load voltage) |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Load Voltage |
Output side / 400 (peak AC / DC) V |
Storage Temperature Range |
-55 to +125 ℃ (with no icing or condensation) |
Output on resistance (Ω) |
A connection/17 (typ.), 35 (max.) (at 5 mA LED forward current, 120 mA continuous load) B connection/11 (typ.), 20 (max.) (at 5 mA LED forward current, 120 mA continuous load) C connection/6 (standard), 10 (maximum) (LED forward current 5mA, continuous load 240mA) (ambient temperature 25°C) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-40 to +85 (no freezing or condensation) |
Insulation Resistance (MOhm) |
Input / output capacity / 1000 (minimum) (withstand voltage 500 V DC, RoH ≦ 60%) |
Continuous load current (mA) |
Output side (ambient temperature 25°C): A connection/120 (peak AC/DC), B connection/120 (DC), C connection/240 (DC) |
Input current (mA) |
LED forward current / 50, repetitive peak LED forward current / 1 (100μs pulse, 100pps), reverse current / 10μ (maximum) (when LED reverse voltage is 5V), trigger LED forward current / 3 (maximum) (continuous load current 120hours) ), (At an ambient temperature of 25 ° C) |
Temperature (℃) |
Joint/125 Soldering condition/260(10s) |
Input Voltage (V) |
LED reverse voltage/5 LED forward voltage/1.0 (minimum), 1.15 (typ.), 1.3 (maximum) (when LED forward current is 10mA) (at ambient temperature of 25°C) |
