| Contact Configuration | DPDT |
| Coil Resistance | 91 Ω |
| Outer Dimensions (mm) | 10x7.8x5.2 |
| Monotaro ID | 41097526 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
DPDT |
Coil Resistance |
91 Ω |
Outer Dimensions (mm) |
10x7.8x5.2 |
Monotaro ID |
41097526 |
Type of Product |
Surface Mount Relay |
Application |
signal |
Model No |
G6K-2F-Y-DC3V |
Power Consumption (mW) |
About 100 (low) |
Coil Voltage |
DC 3 V |
maximum switching power (DC W) |
30 |
Terminal Type |
Surface mount |
Height (mm) |
5.2 |
Length (mm) |
10 |
Switching Current |
1 Amp |
Maximum Switching Voltage |
60 AC V |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Pack of |
1 Pcs |
Specifications |
UL, CSA. Relay G6K series. Ultra-compact and compatible with high-density mounting High withstand voltage AC1500V between coil contacts, and impact withstand voltage 1.5kV 10x160μs (FCC part 68 compliant) Realization By optimizing the distance between the coil and contact terminals, we also have a lineup of Y series with a shock resistant voltage of 2.5 kV 2x10 μs (corresponding to the Telcordia standard). |
Operating Temperature (c) |
70 |
Switching Voltage (VAC) |
125 |
