| Terminal Shape | Printed circuit board terminal |
| Contact Configuration | 1A1B |
| Type | Power relay |
| Contact Mechanism | Single |
Terminal Shape |
Printed circuit board terminal |
Contact Configuration |
1A1B |
Type |
Power relay |
Contact Mechanism |
Single |
Rated Voltage (V) |
DC3 |
Monotaro ID |
46641673 |
Type of Product |
Power Relay |
Model No |
G6CK-2117P-US-DC3 |
Contact Material |
Ag alloy (Cd-free material) |
Part No |
64-3369-63 |
RoHS Directive |
Correspondence |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Coil Rating |
DC 3 V 93.5 mA |
Terminal Structure |
Printed circuit board terminal |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Rated Load Voltage (V) |
AC 250 V 8 Amp (resisti Ve load) AC 250 V 3.5 Amp (inducti Ve load (cosΦ=0.4)) DC 30 V 8 Amp (resisti Ve load) DC 30 V 3.5 Amp (inducti Ve load (L/R=7ms)) |
Rated Coil Voltage |
DC 3 V |
