| Mass (g) | About 90 |
| Terminal Shape | Plug-In Terminal |
| Return Voltage | 30% or more of rated voltage (60 Hz), 25% or more (50 Hz) |
| Operating Temperature Range | -25 to 60℃ (no condensation or freezing) |
Mass (g) |
About 90 |
Terminal Shape |
Plug-In Terminal |
Return Voltage |
30% or more of rated voltage (60 Hz), 25% or more (50 Hz) |
Operating Temperature Range |
-25 to 60℃ (no condensation or freezing) |
Contact Configuration |
2C |
Mechanical Durability |
5 million times or more (opening and closing frequency 18000 times / h) |
Type |
Power Relay |
No. of Pole |
2 Pole |
Power Consumption |
About 2.3 (60 Hz), about 2.7 (50 Hz) |
Monotaro ID |
46690497 |
Operating Voltage |
80% or less of rated voltage |
Type of Product |
Small Power Relay |
Model No |
MKS2PIN-AC24 |
Shock Resistance |
1000 m/s² |
Classification |
Built-in operation indicator |
Electrical Durability |
Over 100,000 times (rated load, switching frequency 1,800 times/h) (ambient temperature 23°C) |
Protection Class |
In a case |
Country of Origin |
CHINA |
Import Country |
Direct Import from Japan |
Operation Indicator |
Mechanical Indicator |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to +60 (with no icing or condensation) |
Contact Resistance (ohm) |
100 mΩ or less (DC 5 V 1 Amp voltage drop method) |
Insulation Resistance (MOhm) |
100 or more (at 500 V DC) |
Rated Coil Voltage |
AC 24 V |
Remark |
Confirm Delivery Date Each Time |
