| Mass (g) | About 40 |
| CR Circuit | None |
| Operating Temperature Range | -25 to 40 ℃ (no condensation or freezing) [-25 to 55 when current is 4 Amp or less] |
| Contact Configuration | 1C |
Mass (g) |
About 40 |
CR Circuit |
None |
Operating Temperature Range |
-25 to 40 ℃ (no condensation or freezing) [-25 to 55 when current is 4 Amp or less] |
Contact Configuration |
1C |
Type |
Bi-Power Relay |
No. of Pole |
1 |
Power Consumption |
About 0.9 |
Monotaro ID |
46632862 |
Type of Product |
Bi-Power Relay |
Model No |
LY1-D-DC48 |
Classification |
Built-in diode type |
Shape |
LY1-D |
Protection Class |
In a case |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Outer Dimensions |
21.5 or less x 42.4 or less x 28 or less mm |
With or Without Diode |
Included |
Terminal Structure |
Plug-In Terminal |
No. Of Pin |
8 |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Operation Ambient Temperature (°C) |
-25 to 40 (with no icing or condensation) , -25 to 55°C when current is 4 Amp or less |
Contact Resistance (ohm) |
50 mΩ or Less (DC 5 V 1 Amp voltage drop method) |
Insulation Resistance (MOhm) |
100 or more (Measure the same part as the withstand voltage with a DC500V insulation resistance meter) |
Rated Coil Voltage |
DC 48 V |
