| Mass (g) | About 20 |
| Terminal Shape | Plug-in terminal |
| Operating Temperature Range | -40 to 70℃ |
| Contact Configuration | 2C Contact |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Mass (g) |
About 20 |
Terminal Shape |
Plug-in terminal |
Operating Temperature Range |
-40 to 70℃ |
Contact Configuration |
2C Contact |
Type |
Built-in operation indicator (AC coil: red) |
No. of Pole |
2-Pole |
Power Consumption |
About 0.9 (60Hz) |
Monotaro ID |
37613554 |
Type of Product |
Mini Power Relay |
Series |
G2R |
Protection Class |
In a case |
Coil Voltage |
AC100/110 V |
Height (mm) |
34 |
Length (mm) |
31.5 |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
With or Without Diode |
None |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Lever Type |
Standard type (latching lever) |
Operation Ambient Temperature (°C) |
-40~+70 (no freezing or condensation) |
Manufacturer Part Number |
G2R-2-SN AC100/(110) |
Contact Resistance (ohm) |
50 or less (DC5V 1A energization voltage drop method) |
Insulation Resistance (MOhm) |
1000 or more |
Specifications |
Mechanical indicator: Standard type |
