| Mass (g) | About 1.5 |
| Terminal Shape | Surface mount terminal |
| Contact Configuration | 2C |
| Minimum Applicable Load | 10 μA 10 mV DC |
Mass (g) |
About 1.5 |
Terminal Shape |
Surface mount terminal |
Contact Configuration |
2C |
Minimum Applicable Load |
10 μA 10 mV DC |
Coil Resistance |
405 Ω (±10%, 20℃) |
Monotaro ID |
73928837 |
Type of Product |
TQ Relay |
Standard |
UL, CSA |
Model No |
ATQ227SA |
Contact Material |
Ag clad with Au |
Contact |
Standard contact type |
Shock Resistance |
980 m/s² (Half-sine pulse: 6ms) |
Power Consumption (mW) |
200 |
Protection Class |
Plastic seal |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz (double amplitude: 3 mm, detection time: 10 μs) |
Shock Resistance (Malfunction) |
490 m/s² (Half-sine pulse: 11 ms, detection time: 10 μs) |
Vibration Resistance (Destruction) |
10 to 55 Hz (double amplitude: 5 mm) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Applicable Voltage (V) |
150% of rated coil voltage (20℃) |
Pack of |
50 Pcs |
Packaging Type |
Stick packaging |
Contact Resistance (ohm) |
Initial: 50 or less (6 V DC 1A voltage drop method) |
Insulation Resistance (MOhm) |
Initial: 1000 or more (measured at the same location as the withstand voltage with a 500 V DC insulation resistance tester) |
Specifications |
Surge voltage resistance (initial): 1500V between contacts 10 x 160 μs |
Rated Coil Voltage |
DC 9 |
