| Contact Configuration | SPST |
| Coil Resistance | 105 |
| No. of Pole | 1 |
| Monotaro ID | 65212658 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
SPST |
Coil Resistance |
105 |
No. of Pole |
1 |
Monotaro ID |
65212658 |
Type of Product |
Power Relay |
Model No |
ST1-DC5V-F |
RoHS Directive |
Correspondence |
Coil Voltage |
5/ DC |
maximum switching power (DC W) |
150 |
Type of Sign |
Board mounting |
Length (mm) |
31 |
Switching Current |
8 Amp |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Maximum Switching Voltage (AC) |
380 V |
Maximum Switching Voltage (DC) |
250 V |
Coil Electricity (mW) |
240 |
Specifications |
UL, CSA, VDE, SEV. ST Series Relays. This PCB-mount power relay is compatible with ICs and is ideal for switching inductive loads. Its high switching capability and high withstand voltage improve stability. Its sealed construction allows for automatic cleaning. High withstand voltage. High switching capacity allows for use in switching inductive and lamp loads. Compact and highly sensitive, allowing for direct IC drive. Dimensions: H11xW14xD31 mm. Sealed construction allows for automatic cleaning. ST-PS relay sockets are available. See part number 103-6836. |
Latch Type |
None |
