| Mass (g) | About 6 |
| Terminal Shape | Printed circuit board terminal |
| Contact Configuration | 1A1B |
| Minimum Applicable Load | 10 mA 5 V DC |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Mass (g) |
About 6 |
Terminal Shape |
Printed circuit board terminal |
Contact Configuration |
1A1B |
Minimum Applicable Load |
10 mA 5 V DC |
Coil Resistance |
45 Ω (±10%, 20℃) |
Monotaro ID |
73938174 |
Type of Product |
DK Relay |
Standard |
UL, CSA, VDE, TUV |
Model No |
AW3031 |
Contact Material |
AgNi-based with Au flash |
Shock Resistance |
980 m/s² (Half-sine pulse: 6ms) |
Power Consumption (mW) |
200 |
Protection Class |
Plastic seal |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz (double amplitude: 1.5 mm, detection time: 10 μs) |
Shock Resistance (Malfunction) |
98 m/s² (Half-sine pulse: 11ms, detection time: 10 μs) |
Vibration Resistance (Destruction) |
10-55 Hz (double amplitude: 3 mm) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Applicable Voltage (V) |
130% of rated coil voltage (20℃) |
Pack of |
50 Pcs |
Contact Resistance (ohm) |
Initial: 30 or less (6 V DC 1A voltage drop method) |
Insulation Resistance (MOhm) |
Initial: 1000 or more (measured at the same location as the withstand voltage with a 500 V DC insulation resistance tester) |
Specifications |
Surge voltage resistance (initial): 10,000V between contacts and coil |
Dimension (mm) |
20x15x10 |
Rated Coil Voltage |
DC 3 |
