| Mass (g) | About 1 |
| Terminal Shape | Surface mount terminal A type |
| Contact Configuration | 2C |
| Minimum Applicable Load | 10 μA 10 mV DC |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Mass (g) |
About 1 |
Terminal Shape |
Surface mount terminal A type |
Contact Configuration |
2C |
Minimum Applicable Load |
10 μA 10 mV DC |
Monotaro ID |
73890556 |
Type of Product |
GQ Relay |
Standard |
UL/C-UL, BSI |
Model No |
AGQ200A09 |
Contact Material |
AgPd with Au clad (fixed), AgPd (movable) |
Shock Resistance |
1000 m/s² (half-sine pulse: 6ms) |
Protection Class |
Plastic seal type |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz (double amplitude: 3.3 mm, detection time: 10 μs) |
Shock Resistance (Malfunction) |
750 m/s² (Half-sine pulse: 6ms, detection time: 10 μs) |
Vibration Resistance (Destruction) |
10 to 55 Hz (double amplitude: 5 mm) |
Contact Specifications |
standard contacts |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Applicable Voltage (V) |
150% of rated coil voltage (20℃) |
Pack of |
50 Pcs |
Operation Ambient Temperature (°C) |
-40 to 85°C (-40 to 70°C in manufacturer's packaging) |
Packaging Type |
Stick packaging |
Contact Resistance (ohm) |
Initial: 100 or less (6 V DC 1A voltage drop method) |
Insulation Resistance (MOhm) |
Initial: 1000 or more (measured at the same location as the withstand voltage with a 500 V DC insulation resistance tester) |
Specifications |
Surge voltage resistance (initial): Between contacts 1500V 10 x 160 μs, Between contacts and coil 2500V 2 x 10 μs |
Rated Coil Voltage |
DC 9 |
Rated Power Consumption (W) |
0.14000000000000001 |
