| Coil Resistance | 1.2k |
| Monotaro ID | 48167526 |
| Type of Product | Power Relay |
| Application | Electric power |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Coil Resistance |
1.2k |
Monotaro ID |
48167526 |
Type of Product |
Power Relay |
Application |
Electric power |
Model No |
HE1ANS48 |
Terminal Type |
screw |
Height (mm) |
44.5 |
Length (mm) |
50 |
Switching Current |
30 Amp |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Maximum Switching Voltage (AC) |
277 V |
Maximum Switching Voltage (DC) |
30 V |
Operation Ambient Temperature (°C) |
-50 |
Specifications |
Ul, Sca, Vde, Tuv.He Series. These Board Mounted Power Relays Have Large Capacity, Long Life And Excellent Surge Resistance. Typical Applications For These Board Power Relays Include Office Equipment, Industrial Equipment And Consumer Electronics. .Large-Capacity, Long-Life, Single-Side Stable Type Surge Voltage 10,000V Or More Pre-Tension And Kick-Off Mechanism Demonstrate Excellent Resistance During Welding Of Contacts Typical Applications Machine Tools, Molding Equipment, Air Conditioners, Heating Equipment |
Operating Temperature (c) |
-50 |
Rated Coil Voltage |
DC48 |
