| Mass (g) | About 8 |
| Terminal Shape | Printed circuit board terminal |
| Contact Configuration | 1A |
| Function | Reflow compatible type |
Mass (g) |
About 8 |
Terminal Shape |
Printed circuit board terminal |
Contact Configuration |
1A |
Function |
Reflow compatible type |
Monotaro ID |
73883364 |
Type of Product |
DW Relay |
Standard |
UL/C-UL, VDE, CQC |
Model No |
ADW1212W |
Rated Current (mA) |
33.3 (set coil), 33.3 (reset coil) |
Protection Class |
Flux tight |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Pack of |
100 Pcs |
Dimension (mm) |
24.0x10.0x18.8 |
Rated Coil Voltage |
DC 12 |
Maximum Allowable Contact Current (A) |
AC 8 |
Contact Rated Control Capacity (Resistive Load) |
AC 250 V 8A |
Maximum Allowable Contact Voltage (V) |
AC 250 |
Operational Function |
2-winding latching type |
Contact Capacity |
Standard type (8A) |
