Ships within 25 days
View
View
View
View
| Mass (g) | About 120 |
| Terminal Shape | Screw terminal |
| Contact Configuration | 1A |
| Type | DC type |
Mass (g) |
About 120 |
Terminal Shape |
Screw terminal |
Contact Configuration |
1A |
Type |
DC type |
Minimum Applicable Load |
100mA 5 V DC |
Monotaro ID |
73891073 |
Type of Product |
HE Relay |
Standard |
UL, CSA, VDE, TUV, TV, CQC |
Model No |
AHE1233 |
Contact Material |
AgSnO2 system |
Shock Resistance |
980 m/s² (Half-sine pulse: 6ms) |
Power Consumption (mW) |
1920 |
Protection Class |
Dust cover |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz (double amplitude: 1 mm, detection time: 10 μs) |
Shock Resistance (Malfunction) |
98 m/s² (Half-sine pulse: 11ms, detection time: 10 μs) |
Vibration Resistance (Destruction) |
10-55 Hz (double amplitude: 1.5 mm) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Applicable Voltage (V) |
110% of rated coil voltage (55℃) |
Pack of |
10 Pcs |
Contact Resistance (ohm) |
Initial: 100 or less (6 V DC 1A voltage drop method) |
Insulation Resistance (MOhm) |
Initial: 1000 or more (measured at the same location as the withstand voltage with a 500 V DC insulation resistance tester) |
Specifications |
Insulation distance: 8 mm or more Surge voltage resistance (initial): 10,000V between contacts and coil |
Dimension (mm) |
50x33x35.8 |
Rated Coil Voltage |
DC 48 |
