| Mass (g) | About 16 |
| Terminal Shape | Plug-in terminal (slim type DC) |
| Contact Configuration | 2C |
| Minimum Applicable Load | 100μA 1 V DC |
Mass (g) |
About 16 |
Terminal Shape |
Plug-in terminal (slim type DC) |
Contact Configuration |
2C |
Minimum Applicable Load |
100μA 1 V DC |
Coil Resistance |
25 Ω (±10%, 20℃) |
Operating Time (ms) |
20 or less at rated coil voltage (at 20°C, not including contact bounce) |
Monotaro ID |
73938874 |
Type of Product |
NC Relay |
Standard |
UL, CSA |
Model No |
AW821860 |
Contact Material |
AgNi-based Au clad |
Shock Resistance |
980 m/s² (Half-sine pulse: 6ms) |
Power Consumption (mW) |
360 |
Protection Class |
Plastic seal |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz (double amplitude: 1 mm, detection time: 10 μs) |
Shock Resistance (Malfunction) |
98 m/s² (Half-sine pulse: 11ms, detection time: 10 μs) |
Vibration Resistance (Destruction) |
10-55 Hz (double amplitude: 2 mm) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Applicable Voltage (V) |
135% of rated coil voltage (50℃) |
Pack of |
20 Pcs |
Contact Resistance (ohm) |
50 or less (6 V DC 1 A voltage drop method) |
Insulation Resistance (MOhm) |
100 or more (measured at the same location as the withstand voltage with a 500 V DC insulation resistance tester) |
Dimension (mm) |
38.1x11.2x27.8 |
Rated Coil Voltage |
DC 3 |
Open Voltage (V) |
10% or less of the rated coil voltage (20°C, initial) |
