| Mass (g) | About 23 |
| Contact Configuration | 5a1b |
| Function | With LED display |
| Type | Slim type |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Mass (g) |
About 23 |
Contact Configuration |
5a1b |
Function |
With LED display |
Type |
Slim type |
Minimum Applicable Load |
1 mA 5 V DC |
No. of Pole |
6P |
Monotaro ID |
73889278 |
Type of Product |
SF Relay Slim Type |
Standard |
UL/C-UL, TUV, KoreanSMark, CQC |
Model No |
AG1S151 |
Contact Material |
Au flash on AgSnO2 series |
Shock Resistance |
1000 m/s² (half-sine pulse: 6ms) |
Protection Class |
Flux tight type |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Vibration Resistance (Malfunction) |
10 to 55 Hz (double amplitude: 1.5 mm, detection time: 10 μs) |
Shock Resistance (Malfunction) |
200 m/s² (Half-sine pulse: 11ms, detection time: 10 μs) |
Vibration Resistance (Destruction) |
10-55 Hz (double amplitude: 1.5 mm) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Applicable Voltage (V) |
110% of rated coil voltage (20℃) |
Pack of |
50 Pcs |
Contact Resistance (ohm) |
Initial: 100 or less (6 V DC 1A voltage drop method) |
Insulation Resistance (MOhm) |
Initial: 1000 or more (measured at the same location as the withstand voltage with a 500 V DC insulation resistance tester) |
Dimension (mm) |
50x13x24 |
Rated Coil Voltage |
DC 12 |
Rated Power Consumption (W) |
About 0.5 |
