| Contact Configuration | 3PDT |
| Coil Resistance | 110 Ω |
| No. of Pole | 3 |
| Type of Product | Power Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
3PDT |
Coil Resistance |
110 Ω |
No. of Pole |
3 |
Type of Product |
Power Relay |
Application |
General Purpose |
Contact Material |
Silver Alloy |
Mounting Type |
Plug In |
Series |
R15 |
Coil Voltage |
12 V DC |
Height |
35 mm |
Length |
35 mm |
Terminal Type |
Plug In |
Latching |
No |
Switching Current |
10 Amp |
Depth |
54.4 mm |
Coil Power Consumption |
1.5 W |
Country of Origin |
Poland |
Isolation Coil To Contact |
2.5 kV AC |
Life Expectancy |
200000 (Electrical) cycles, 20000000 (Mechanical) cycles |
Maximum Operating Temperature |
+70°C |
Minimum Operating Temperature |
-40°C |
Name of Manufacturer/Packer/Importer |
Relpol |
Maximum Switching Voltage DC |
24 V DC |
Maximum Switching Voltage (AC) |
440 V |
Maximum Switching Voltage (DC) |
24 V DC |
Product Code |
8052210 |
Manufacturer Part Number |
R15-2013-23-1012-WTL |
Maximum Switching Voltage AC |
440 V |
