| Type | Standard |
| Coil Resistance | 300 Ohms |
| Type of Product | Power Relay |
| Contact Material | Silver Alloy (Ag) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Standard |
Coil Resistance |
300 Ohms |
Type of Product |
Power Relay |
Contact Material |
Silver Alloy (Ag) |
Mounting Style |
Panel Mount |
Series |
725B |
Coil Voltage |
24 V DC |
Switching Voltage |
300 V AC |
Contact Current Rating |
25 Amp |
Coil Termination |
Screw |
Relay Contact Form |
2 Form A (DPST-NO) |
Height |
67.7 mm |
Width |
33.1 mm |
Length |
53.2 mm |
Coil Type |
Non-Latching |
Contact Termination |
Screw |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Schneider Electric Relays |
Ordering ID |
528-725BXXSC3ML-24D |
Manufacturer Part Number |
725BXXSC3ML-24D |
Data Sheet |
https://www.mouser.in/datasheet/3/187/8/orgid_78_dist_849_lang_42_form_no_documenttype_plain_productid_725BXXSC3ML_24D.pdf |
RoHS Compliant |
Yes |
