| Type | Standard |
| Coil Resistance | 62 Ohms |
| Type of Product | Power Relay |
| Contact Material | Silver Tin Oxide (AgSnO2) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Standard |
Coil Resistance |
62 Ohms |
Type of Product |
Power Relay |
Contact Material |
Silver Tin Oxide (AgSnO2) |
Mounting Style |
Chassis Mount |
Coil Voltage |
32 V DC |
Switching Voltage |
28 V DC |
Contact Current Rating |
300 Amp |
Coil Termination |
Screw |
Relay Contact Form |
1 Form X (SPST) |
Coil Current |
400 mA |
Coil Type |
Non-Latching |
Contact Termination |
Screw |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity / Kissling |
Ordering ID |
571-29-311-12 |
Manufacturer Part Number |
29-311-12 |
Data Sheet |
https://www.mouser.com/catalog/specsheets/tycoelectronics_09222020_KI-Relay29-300A.pdf |
RoHS Compliant |
Yes By Exemption |
IP Rating |
IP67, IP6K9K |
