| Type | Standard |
| Coil Resistance | 288 Ohms |
| Type of Product | Power Relay |
| Contact Material | Silver Cadmium Oxide (AgCdO) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Standard |
Coil Resistance |
288 Ohms |
Type of Product |
Power Relay |
Contact Material |
Silver Cadmium Oxide (AgCdO) |
Mounting Style |
Panel Mount |
Series |
PRD |
Coil Voltage |
24 V DC |
Switching Voltage |
600 V AC, 125 V DC |
Contact Current Rating |
30 Amp |
Relay Contact Form |
2 Form A (DPST-NO) |
Height |
63.5 mm |
Width |
63.8 mm |
Length |
85.7 mm |
Coil Current |
84 mA |
Coil Type |
Non-Latching |
Contact Termination |
Screw |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
TE Connectivity / P&B |
Ordering ID |
655-PRD-7DG0-24 |
Manufacturer Part Number |
PRD-7DG0-24 |
Data Sheet |
https://www.te.com/commerce/DocumentDelivery/DDEController?Action=srchrtrv&DocNm=1308242_PRD&DocType=DS&DocLang=EN |
RoHS Compliant |
In Transition |
