| Contact Configuration | SPST |
| Coil Resistance | 4800 Ω |
| No. of Pole | 1 |
| Type of Product | Power Relay |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Contact Configuration |
SPST |
Coil Resistance |
4800 Ω |
No. of Pole |
1 |
Type of Product |
Power Relay |
Application |
I/O Modules, PLCs, Temperature Controls |
Contact Material |
Silver Alloy |
Mounting Type |
PCB Mount |
Series |
PCN |
Coil Voltage |
24 V DC |
Height |
12.5 mm |
Length |
20 mm |
Terminal Type |
PCB Pin |
Latching |
No |
Switching Current |
5 Amp |
Depth |
5 mm |
Coil Power Consumption |
120 mW |
Country of Origin |
China |
Isolation Coil To Contact |
4 kV |
Life Expectancy |
10000000 (Mechanical) Operations, 70000 (Electrical) Operations |
Maximum Operating Temperature |
+85°C |
Minimum Operating Temperature |
-30°C |
Name of Manufacturer/Packer/Importer |
TE Connectivity |
Maximum Switching Voltage DC |
125 V DC |
Product Code |
9097924 |
Manufacturer Part Number |
7-1461491-6 |
Maximum Switching Voltage AC |
277 V |
Standards Met |
CQC, cULus, VDE |
